How to deploy Grafana and Prometheus to Kubernetes cluster via helm
How to deploy Grafana and Prometheus to a Kubernetes cluster running on Raspberry Pi 4 using Helm charts.
Deploy K3S at Raspberry Pi 4
First, install K3S on the Raspberry Pi 4. This command downloads and runs the K3S installer, setting the kubeconfig permissions and adding a TLS SAN for the node IP address.
1
curl -sfL https://get.k3s.io | sh -s - --write-kubeconfig-mode 644 --tls-san 192.168.0.241 raspberry4-k3s
Setup /etc/hosts at your laptop (because of Ingress)
Update your local /etc/hosts file so that the Ingress hostname resolves to the Raspberry Pi IP address. This is required for accessing services through the Ingress controller.
1
2
3
4
5
6
7
8
9
cat /etc/hosts
##
# Host Database
#
...
192.168.0.241 raspberrypi
...
Deploy Grafana
Deploy Grafana via Helm with Ingress enabled, a Prometheus datasource preconfigured, and a default dashboard loaded from Grafana.com. Persistent storage uses the local-path storage class provided by K3S.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
helm upgrade --install grafana grafana/grafana \
--set ingress.enabled=true \
--set "ingress.hosts[0]=raspberrypi" \
--set ingress.path=/grafana \
--set grafana\\.ini.server.root_url="%(protocol)s://%(domain)s/grafana" \
--set grafana\\.ini.server.serve_from_sub_path=true \
--set "datasources.datasources\\.yaml.datasources[0].name=PromethusRaspberryPi" \
--set "datasources.datasources\\.yaml.datasources[0].type=prometheus" \
--set "datasources.datasources\\.yaml.datasources[0].url=http://prometheus-server/prometheus" \
--set dashboards.default.monitoring.gnetId=15120 \
--set dashboards.default.monitoring.revision=3 \
--set dashboards.default.monitoring.datasource=PromethusRaspberryPi \
--set "dashboardProviders.dashboardproviders\\.yaml.providers[0].name=default" \
--set "dashboardProviders.dashboardproviders\\.yaml.providers[0].orgId=1" \
--set "dashboardProviders.dashboardproviders\\.yaml.providers[0].folder=default" \
--set "dashboardProviders.dashboardproviders\\.yaml.apiVersion=1" \
--set "dashboardProviders.dashboardproviders\\.yaml.providers[0].type=file" \
--set "dashboardProviders.dashboardproviders\\.yaml.providers[0].editable=true" \
--set "dashboardProviders.dashboardproviders\\.yaml.providers[0].disableDeletion=true" \
--set "dashboardProviders.dashboardproviders\\.yaml.providers[0].options.path=/var/lib/grafana/dashboards" \
--set persistence.enabled=true \
--set persistence.type=pvc \
--set persistence.size=1Gi \
--set persistence.storageClassName=local-path
Deploy Prometheus
Deploy Prometheus using the community Helm chart. This configuration disables alertmanager, kube-state-metrics, pushgateway, and node-exporter to keep the installation lightweight on the Raspberry Pi. Ingress is enabled under the /prometheus path.
1
2
3
4
5
6
7
8
9
10
11
12
13
helm upgrade --install prometheus prometheus-community/prometheus \
--set alertmanager.enabled=false \
--set kubeStateMetrics.enabled=false \
--set pushgateway.enabled=false \
--set nodeExporterenabled=false \
--set server.ingress.enabled=true \
--set "server.ingress.hosts[0]=raspberrypi" \
--set server.ingress.path=/prometheus \
--set server.prefixURL=/prometheus \
--set "server.extraFlags[0]=web.external-url=/prometheus" \
--set server.persistentVolume.enabled=true \
--set server.persistentVolume.storageClass=local-path \
--set server.persistentVolume.size=2Gi
